Nautilus R616 User Manual

8
ASSEMBLY
1a. Attach Stabilizers to Frame
Note: Hardware(*) is pre-installed on the stabilizers and not on Hardware Card. Make sure transport wheels on
the front stabilizer point forward.
1b. Attach the Seat Rail End Cap to the Frame Assembly
*
6mm
*
*
X2
*
6mm
*
*
X2
12
8
10
9
