44
AC
NLS U628/R628 Wiring Diagram
AC Power input
220V - 240V
Console
Contact
Heart Rate
(CHR) sensor
HR cable, 4Pin
I/O (Data)
cable, 6Pin
LN
Power inlet
cable
Resistance
Up
Down
Resistance
Up
Down
EMS
MCB,
W
atts
RPM sensor
(magnetic reed switch)
RPM
Sensor
cable,
2Pin
Electromagnet
EMS Cable,
2Pin
W
atts/
DC In
cable,
4Pin
Wireless
Heart Rate
Module
HR cable, 3Pin
43
45
Table of Contents
Table of Contents
1
Important Safety Instructions
2
Safety Warning Labels and Serial Number
3
Earthing Instructions
3
Leveling the Machine
5
Moving the Machine
5
Heart Rate Chest Strap Battery Replacement
6
Troubleshooting
7
Console Service Mode
10
Maintenance Parts Exploded View
13
MCB Watts
14
Console
14
EMS Engine
15
Heart Rate/Resistance Cable Assembly in the Mast
44
Seat Recline Shock Assembly
59
Shrouds
65
