1RWH<RXUPDFKLQHPD\QRWPDWFKWKHLPDJH)RUUHIHUHQFHRQO\

To remove the Main Shrouds, start at Step 1. To remove only the Rear

Shrouds, go to Step 10.

 8VLQJDÀDWKHDGVFUHZGULYHUUHPRYHWKHWKUHDGHG&DS$

IURPWKH&UDQN$UP%WRH[SRVHWKH+H[+HDG%ROW&

 8VLQJDZUHQFKDQGVRFNHWUHPRYHWKH+H[+HDG%ROW&

3. Thread the Crank Puller into the Crank Arm (B). When the

Crank Puller is in the correct position, only 1-2 threads on the

outer portion (CP2) of the Crank Puller should show.

Note: Be sure the end of the Bolt (CP1) of the Crank Puller is

ÀXVKZLWKWKH1XW&3DVVKRZQEHIRUHXVH

4. Using a wrench, turn the inner portion (CP3) of the Crank

3XOOHUFORFNZLVH7KH&UDQN$UP&ZLOOVOLGHRႇDVLWLV

tightened.

5. Twist the Crank Covers (P) toward the back of the machine

to disengage the inner tabs. Carefully remove the Crank Covers

and set them safely aside for reassembly.

Disconnect all power to the machine before you service it.

CP1 CP2 CP3
