Nautilus T618 Service Manual

79
7.Usinga6mmhexwrench,removetheindicatedscrewfromtheFront
Roller.
8. Lift and pivot the Front Roller out of the Frame. This will free the Drive
Belt from the Front Roller.
9. Replace the old Drive Belt with the new Drive Belt around the Front
Roller.
10. Insert the end of the Front Roller with the Drive Pulley into the Frame,
and pivot the other end into the Bracket.
11.Usinga6mmhexwrench,attachtheFrontRollertotheBracket.
Note: Tighten the hardware until the Front Roller is centered in the
Bracket.
Front Roller
=

Nautilus T618 Specifications

General

Foldable	Yes
Bluetooth Connectivity	Yes
Cooling Fan	Yes
Running Surface	20" x 60"
Incline Range	0% to 15%
Speed Range	0 to 12 MPH
Display	LCD
Programs	26
Heart Rate Monitoring	Yes
Weight Capacity	350 lbs
Audio	Yes
Dimensions	57.6" H
