Nautilus T626 Service Manual

170
4. Using a #2 Phillips screwdriver, remove the hardware that
attaches the Filter to the Frame.
5.RemovetheconnectorsfromtheoldFilterandattachtothe
new Filter. Be sure not to crimp any cables.
Note: Be sure to note where all cables attach for re-assembly.
6. Using a #2 Phillips screwdriver, attach the new Filter to the
Frame. Be sure not to crimp any cables.
7. Using a #2 Phillips screwdriver, remove the hardware that
attaches the Choke to the Frame.
8. Remove the connectors from the old Choke and attach to the
new Choke. Be sure not to crimp any cables.
Note: Be sure to note where all cables attach for re-assembly.
9. Using a #2 Phillips screwdriver, attach the new Choke to the
Frame. Be sure not to crimp any cables.
10. Re-install all remaining parts that were removed in reverse
order.
Choke
Filter
MCB

Nautilus T626 Specifications

General

Quantity per pack	1 pc(s)
Foldable	Yes
Incline range	0 - 15 %
Maximum speed	19.3 km/h
Minimum speed	0 km/h
Product color	Black, Grey
Number of programs	26
Maximum user weight	136 kg
Backlight color	Blue

Weight and Dimensions

Width	- mm
Weight	- g
Running area (W x L)	20 x 60 mm
Running belt thickness	2 mm
Running deck thickness	25 mm
