Navkom R7 User Manual

16 17
Add your reader in the X-Manager app.
Perform the factory reset.
1
2
Start by entering administrator ngerprints on the reader/by pressing Button 1 on the control unit/
Button A on the remote control.
3
HYBRID CONTROL
FINGERPRINT ENTRY AND READER CONTROL
Once the administrator’s ngerprints are entered, you can use the app only to unlock the door or manage
the LED lighting.
4
Download the X-manager app to your smartphone or tablet from the Google Play Store
(Android) or the App Store (Apple).
CONNECTING THE PHONE TO THE READER
APP FUNCTIONS
Pressing the Activate - relay 2 tab will activate
the device connected to relay 2 (alarm, garage
door, side door, etc).
Pressing the Touch to open - relay 1 tab will
unlock the door.
LED settings: If there is LED lighting in the
door, it can be connected to the system and
controlled by the X-manager. It is possible to
adjust the brightness (1% to 100%) and the
schedule for turning the lighting on/o:
- 24H: The LED lighting will be switched on
continuously.
- Auto: The LED lighting will automatically turn
on at sunset and turn o at sunrise.
- Custom: You can set the switch-on and switch-
o times yourself. You can set two intervals in
the day when the lighting will be on.
Relay opening time: The length of time
during which the relay is switched on can be
adjusted to between 1 and 60 seconds. This
setting is useful when using an electric strike.
Blue backlight: if the blue backlight that
lights up when the reader is in standby mode
bothers you, you can turn it o.
2
3
1
4
5
1
2
3
4
5
Once the ngerprints are entered, you can connect to the reader and control both relays and LED settings
in the app.
APPLE
ANDROID
ON THE SENSOR
WITH REMOTE CONTROL
WITH BUTTONS ON CONTROL UNIT

Navkom R7 Specifications

General

Brand	Navkom
Model	R7
Category	Control Unit
Language	English
