Navman Qube 300 User Manual

1 Installation and Troubleshooting Guide
34
1.14 Dimensions and Specifications
Physical
l Weight: 320 g
l Packed Weight (Gift Box): 600 g
l Case Material: Bayer KU2 1514
ABS/Polycarbonate blend
l Tamper Cover: Polycarbonate
Current Consumption at 13.8 V (27.6 V)
l Sleep State: <3 mA @ 12 V DC
l Awake, modem ON: 70 mA (35 mA)
l Awake, average transmit event once
every one minute: 120 mA (60 mA)
l Peak transmit current: 250 mA (130 mA)
l Battery charging: additional 150 mA (80
mA)
Power Supply
l Nominal operating voltage: 12 or 24 V
vehicle supplies
l Minimum operating voltage: 8 V DC
l Maximum operating voltage: 30 V DC
Digital Output
l Maximum sink current 250 mA (over cur-
rent protection/shut-off)
Temperature Monitoring
l Maximum of six Navman Wireless
digital temperature probes
l Maximum 30 m cable length per install-
ation
