X350 and X550 User Manual
Page 11
4. Insert one PCI card and secure the bracket to the chassis with a retaining screw
(or other fastening mechanism specific to your PC). Note: The X550 is a full-
height PCI card, and the X350 is a half-height PCI card.
Optional installation of a second PCI card (matched pairs only)
If the system has a second available PCI slot and you wish to use a second X-series kit,
insert the second card into the available slot and secure the card to the chassis. Note
that only matched sets of cards are supported. For example, you can use two X550
cards in a PC or two X350 cards. You cannot use both an X350 and an X550 card in the
same system.
5. Replace the system cover and reconnect all peripheral and power cables.
