6-88 Disk Image Backup and Recovery Tool
Backups to separate slots in the Recovery Tool only increase the total storage required by
the amount of data added to the image. When the contents of the OS partition become
too large to store in the 8GB local Recovery Partition, then one of the alternate storage
methods available (USB or network) should be used to store backups.
Output Options
There are three output options.
• Hard Disk Drive/Solid State Device
• USB Device
• Network
Note: Windows 7 images require a minimum of 4GB available on the Network,
Local Drive, or USB drive. "POSReady 7" requires a minimum of 2GB. Make sure
there is enough space is available on the storage media. Image sizes vary depending
on applications and database sizes.
1. Select the arrow that points to the desired output.
Example: Select the USB Save Button.
To Next Page
