Chapter 3: Hardware Installation 3-3
Connecting to a POS
Thefollowingillustrationsshowthecableconnectionsforthe5943andahost
terminal.Therearetwocablesrequired.
 DVIorVGAcableforvideo
 PoweredUniversalSerialBus(USB)forpower
Note: OptionalPowerBrickisavailablewhenUSBpowerisnotavailableonthe
hostterminal.
DVI Connections (Video)
ConnecttheVGACabletotheVGAconnectorsonboththe5943LCDandhost
terminal.
30305
DVI
DVI
497-0446721 - 1.0 m
(1432-C191-0010)
497-0446722 - 4.0 m
(1432-C191-0040)

