3-6 Chapter 3: Hardware Installation
Power Brick Connections (Power)
1. ConnecttheUSBPowerCabletothe5943Powerconnector.
2. ConnectthePowerBrickDCCabletotheUSBPowerCable.
3. ConnecttheACPowerCordtothePowerBrickandanACoutlet.
30308
a
Power
497-0475509 - 4.0 m
(1432-C426-0038)
Power Brick
497-0471714
(5967-K100)
AC Power Cord
(Country Specific)
A
C

