Neato Robotics Botvac D7 Connected User Guide

3
4
Overview
12
11
2
10
1
3
4
1 Laser Cover
2 Top
3 Dirt Bin and Filter
4 Handle
5 Start Button
6 House Clean Icon
7 Spot Clean Icon
8 Battery Icon
9 Wi-Fi Icon
10 Front Bumper
11 Boundary Marker (included in some models)
12 Charge Base
13 Brush
14 Wall Following Sensor Window
15 Side Brush (available on specific models only)
16 Wheels
17 Drop Sensor Window
18 Brush Guard
19 Battery Door
20 Maintainance Tip Label
21 Robot Label
22 Charging Contacts
23 Upgrade Cable (included in some models)
24 Cleaning Tool (included in some models)
14
24
23
13
17
19
20
21
15
16
18
22
HOUSE CLEAN LED shows:
· Whole House Clean
· House Clean Error
SPOT CLEAN LED shows:
· 6' x 6' Spot Clean
· Spot Clean Error
WI-FI LED shows:
· Wi-Fi connection
status during pairing
· Out of range or
other status
BATTERY LED shows:
· Charge State
· Battery Errors
NOTE: Icon light details are described later in this user guide.
Requirements: You need Wi-Fi, an iOS or Android phone or
tablet, and a Neato account (free) in order to use some features.
(filter may
vary by model)
English
TIPS
To keep your robot out of places you don’t
want it to go, set down boundary markers
(included in specific models, however
Neato Boundary Markers are compatible
with all Neato robots) or “No-Go” Lines to
MyFloorPlan (on specific models).
You can use scissors to cut boundary
markers to a shorter length.
You can use removable tape to keep
boundary markers flat on the floor.
To do a Reset of the Neato robot, press and
hold the Start button for 15 seconds and all
the lights will turn o. Press Start button
once more to turn the robot back on.
The combo brush oers superior pick-up
of pet hair, reduced noise during operation,
and is ideal for homes with multiple types of
flooring.
The spiral blade brush (sold separately)
oers deep cleaning performance across all
floor surfaces.
Shiny surfaces and black floors might cause
navigation issues.
Before connecting your robot to your Neato
account, view the How-To Video online at
www.NeatoRobotics.com/Support
Important Items and Tips
IMPORTANT ITEMS
Keep your robot away from liquids and wet
areas. Move or cover pet bowls and plant trays.
Clear the area of small items such as toys
and clothing.
Tie up wires, curtains and other low-hanging
items.
Thick carpet on top stair may aect the
ability of the robot’s navigation system to
prevent falls (top stair with low pile carpet is
OK). To make sure your robot sees the drop,
place boundary markers 6 inches/15cm from
the edge of the stair.
Keep your Neato inside the house. It was not
designed for outdoor cleaning or freezing
temperatures.
IMPORTANT: Please observe your Neato robot during the first few cleaning runs and make any adjustments to the cleaning environment to optimize navigation. Also, while Neato robots have a
smart navigation system that avoids obstacles, the robot may occasionally bump into furniture, objects pets and people. Therefore, if you have special objects that could potentially be damaged
by the bumping, remove these objects from the room or use boundary markers. Similarly, the Neato robot’s rotating brush operates like a regular upright vacuum cleaner, so do not use the
Neato robot on floors or rugs (e.g., with fringes) that you would not use a regular upright vacuum on. Neato Robotics is not responsible for any damage to furniture, objects, rugs, or flooring.
Start Button & LED Lights
5
6
7
8
9

Neato Robotics Botvac D7 Connected Specifications

General

Shape	D-shape
Product color	Black, Platinum
Remotely operated	Yes
Dust container type	Bagless
Number of filters	1 pc(s)
Compatible products	Apple Watch, Amazon Alexa, Google Home, Neato Chatbot, IFTTT, etc
Battery life	460 m²
Charging time	1.5 h
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	4200 mAh
AC input frequency	50 - 60 Hz
Power consumption (typical)	61 W
Efficiency	99 %
HEPA class	HEPA 12
Noise level	75 dB
Wet mopping	No
Certification	CE, FCC, WEEEE
Navigation type	Intelligent, LaserSmart, Mapping
Number of brushes	2
Integrated sensors	Infrared sensor
Programming period	7 day(s)
Vacuum air filtering	HEPA
Dust capacity (total)	0.7 L
Dirt separating method	Cyclonic/filtering
Vacuum cleaner programs	Auto, Carpet, Intensive, Manual, My Space, Repeat, Spot, Turbo
Floor surfaces supported	Carpet, Hard floor, Laminate, Linoleum, Parquet, Tiles, Wood
Mobile operating systems supported	Android, iOS
Package type	Box

Weight and Dimensions

Depth	319 mm
Width	336 mm
Height	100 mm
Weight	3500 g
Working width	276 mm
