6. SPECIFICATIONS
This section provides technical information about the GT950 Projector’s performance.
Model Number GT950
Optical
LCD Panel 0.9” p-Si TFT active-matrix with Micro Lens Array 1024768 dots
Lens Motorized zoom, motorized focus, motorized lens shift
F2.0 – 2.6 f=36.7 – 44.0 mm
Lamp 200W NSH lamp (160W in Eco mode)
The lamp, under normal operating conditions, is warranted for 1500 hours of operation time within 6 months.
Image Size 25 – 300 inches (635 – 7620 mm) diagonal
Projection Distance 3.9 – 39.4 ft (1.2 - 12.0 m)
Electrical
Inputs Video (NTSC / PAL / PAL-M / PAL-N / PAL60 / SECAM / NTSC4.43)
Horizontal Frequency : 15 – 100 kHz
Vertical Frequency : 48 – 120 Hz
Video Bandwidth RGB: 80 MHz
Color Reproduction Full color, 16.7 million colors simultaneously.
Horizontal Resolution 550 TV lines : NTSC / PAL / PAL-M / PAL-N / NTSC4.43 / YCbCr
350 TV lines : SECAM
RGB: 1024 dots horizontal, 768 dots vertical
Power Requirement 100 – 120 / 200 – 240 VAC, 50 / 60 Hz
Input Current 3.4 A (100 – 120 VAC) / 1.7A (200 – 240 VAC)
Mechanical
Dimensions
14.3" (W)6.4" (H)12.7" (D) / 362mm (W)163mm (H)323mm (D) (not including lens and feet)
Net Weight 15.9 lbs / 7.2 kg
Environmental Considerations
Operational Temperatures: 32˚ – 95˚F (0˚ to 35˚C), 20 – 80% humidity
Storage Temperatures: 14˚ – 122˚F (-10˚ to 50˚C), 20 – 80% humidity
Installation angle range: +/- 10°
Regulations UL Approved (UL 1950, CSA 950)
Meets DOC Canada Class B requirements
Meets FCC Class B requirements
Meets AS/NZS3548 Class B
Meets EMC Directive (EN55022, EN55024, EN61000-3-2, EN61000-3-3)
Meets Low Voltage Directive (EN60950, TUV GS Approved)
LCD panels are inherently susceptible to bad pixels.
The LCD panel may have pixel failures at the rate of 0.01% or less.
We provide information about our projectors through the World Wide Web at http://www.nec-pj.com/
The specifications are subject to change without notice.
