Bot t om fram eM6 screws
When using t he 8 x 8 fram e set , use t he bot t om fram e connect ing part t o inst all the bot tom fram e.
Bot t om fram e connecting scr ew ( PM3)
(8 red circles)
Bot t om fram e connecting scr ew ( KM3)
(8 blue circles)
Bot t om fram e connecting part
2.5 I nst all t he cabinet hanger pins t o the back of the cabinets
I nsert t he hanger pins int o the four corners of the cabinets up to where there is a difference in their diam et er.
Hanger pin
LED cabinet
M6
15 m m
Hanger pin
To Next Page
