(2) LAN cable connect ion
Connect the LAN cables for the signal bet ween t he LED m odules. Use the t hrough holes t o pass t he cables
between t he m odules.
Six t hrough holes for t he LAN cables
LAN connectors
[ Conn e ct ion ex a m ple 1 ] Connect ing from bottom t o t op using m ult iple port s
