English - 26
[ Conn e ct ion ex a m ple 2 ] Connect ing all the LED m odules using a single LAN cable
Hub board
Connect t he cable to t he LAN connect or
on the left.
Do not use t he LAN connect or on the
right .
I nsert the LAN cable int o t he thr ough hole and connect it t o
the LAN connect or on t he left.
LAN cable from t he LED controller
