English - 32
[Conguration example]
The set t ing values are given for t he following exam ple where 16 LED- E012i m odules ( pixel pit ch of 1.25 m m )
are installed in a 4 (columns) x 4 (rows) conguration.
CONTROL INPUT OUTPUT
(1) Wit h a pixel pitch of 1.25 m m , ent er Width= 480 and Height = 270 under “ Receiver Card Size” ( g) .
Do not use t he but t ons locat ed next t o the values.
(g)
