Select “ St andard Screen” under “Screen Type” ( d).
The sett ings in “ Sending Card Num ber” ( e) and “ Ethernet Port No.” ( f ) vary depending on t he
connected LED cont roller.
(d)
(e)
(h)
(f)
(g)
(i)
Ent er t he value in t he table below under “Receiving Card Size” ( g).
Product nam e LED- E012i LED- E015i LED- E018i LED- E025i
Pixel pit ch 1.25 m m 1.56 m m 1.88 m m 2.50 m m
Num ber of displayed pixels
(resolution/ m odule)
Width 480
Height 270
Width 384
Height 216
Width 320
Height 180
Width 240
Height 135
[ Colum ns/ Rows] Ent er t he num ber of inst alled screens under “ Colum ns/ Rows” (h) ( the num ber of vert ically
inst alled screens in Colum ns, and t he num ber of horizont ally inst alled screens in Rows) .
