2. Installation and Connection
18
2-3. Connecting the various control terminal
For control, your projector comes with such ports as the PC control terminal and the Ethernet port (RJ-45).
• PC control terminal (RS-232) --------------- Use this terminal when controlling the projector in serial connection from a PC.
• Ethernet port (LAN) --------------------------- Use this port when controlling the projector in LAN connection from a PC.
GP I/O 3D RS-232
USB
REMOTE
LAN
PC
RS-232C
Ethernet cable
To Next Page
