1. Introduction
4
Top View
ITEM LABEL DESCRIPTION SEE PAGE:
1.
Lens control panel See 3Lens Controls
7
2.
Right-hand speaker Right-hand speaker
—
3.
Lamp cover Remove cover to replace lamp or color wheel
107
4.
Exhaust vent Exhaust vent – do not obstruct
—
5.
OSD control panel See 3OSD Controls and Status LEDS
8
6.
Rear intake vent Rear cooling intake – do not obstruct
—
7.
Left intake vent Left-hand cooling intake – do not obstruct
—
