NEC NP4001 - Bottom View

1. Introduction
6
Bottom view
ITEM LABEL DESCRIPTION SEE PAGE:
1.
Height adjusters Adjust projection height
44
2.
Intake vent Color wheel cooling vent – do not obstruct
—
3.
Front filter
Keep the fan free of dust – clean regularly for
optimum performance
103
4.
Ceiling support holes
Contact your dealer for information on
mounting the projector on a ceiling
—
5.
Security chain
opening
Attach anti-theft device –
see
u Using the Physical Lock
60
6.
Rear filter
7.
Side filter
Keep the fans free of dust –
clean regularly for optimum performance
103
CAUTION
With ceiling installation, use approved mounting hardware & M4 screws;
maximum depth of screw: 12 mm; distance from ceiling/ wall: 50/50 cm,
20/20 inch for proper ventilation; distance from fluorescent lamps: at least
50 cm front and back of then projector. For permanent installations, follow
local codes.
