3. Projecting an Image (Basic Operation)
Use the adjustable tilt foot lever, the zoom lever or the focus ring to adjust the picture size and position.
Adjusting the Picture Size and Position
NOTE*: See “
Correcting Keystone Distortion” on page 28 for Keystone.
* In the above drawings, cables are omitted for clarity.
Adjusting the focus
[Focus ring]
Adjusting the throw angle (the height of an image)
[Tilt foot]
Finely adjusting the size of an image
[Zoom lever]
Adjusting the left and right tilt of an image
[Rear foot]
Adjusting the keystone correction
[Keystone] *
(
→
page 27)
