❺ Mounting the cable cover (sold separately)

Mountingtheseparatelysoldcablecover(NP04CV)ontheprojectorallowsyouhidethecablesforacleaner

appearance.

CAUTION

• Aftermountingthecablecover,besuretofastenusingthescrewsprovided.Ifnot,thecablecovercouldfall,

damagingthecablecoverandpossiblyresultingininjury.

• Donotbundlethepowercordandplaceitunderthecablecover.Doingsocouldleadtore.

• Donotapplyexcessiveforcetothecablecover.Doingsocoulddamagethe cablecover,resulting inthe

projectorfallingorcausinginjury.

Mounting

Preparations:

1. Connectthepowercordandcablestotheprojector(theconnectioncordsareomittedfromthediagrams).

2. PrepareaPhillipsscrewdriver.

1. Insert the two round protrusions on the left and right edges

of the cable cover into the grooves in the bottom of the

projector to line it up.

NOTE:Becarefulnottoletthepowercordandcablesgetpinchedbythe

cablecover.

2. Turn the cable cover screw clockwise.

• Tightenthescrewsecurely.

Removing

1. Turn the cable cover screw counterclockwise until it turns

loosely.

• Holdthecablecoverwhiledoingthistopreventitfromfall-

ing.

• Thescrewdoesnotcomecompletelyoff.

2. Remove the cable cover.

• Turnthecablecoveralittle,thenliftitoff.
