8. Appendix
❷ Specifications
This section provides technical information about projector’s performance.
Optical
Model Number P554U P474U P554W P474W P604X P603X PE523X
LCDPanel 0.64inchLCDwithMicroLensArray(AspectRatio16:10) 0.63inchLCDwithMicroLensArray
(AspectRatio4:3)
Resolution*
1
1920×1200pixels(WUXGA) 1280×800pixels(WXGA) 1024×768pixels(XGA)
Lens F=1.50-2.08,f=17.2-27.7
mm
F=1.7–2.2,f=17.4–29.0mm
Zoom Manual(ZoomRatio=1.6) Manual(ZoomRatio=1.7)
Focus Manual
Lensshifting H:±15%,V:+55%,-0% H:±15%,V:+50%,-0%
Lamp ECOMODE
OFF
330 W 305 W 330 W 305 W 330 W 305 W
NORMAL 264 W
ECO 198W
LightOutput*
2
*
3
5,300lumens 4,700lumens 5,500lumens 4,700lumens 6,000lumens 5,200lumens
NORMAL 80% 86% 80% 86% 80% 86%
ECO*
4
60% 65% 60% 65% 60% 65%
ContrastRatio*
3
(fullwhite:fullblack)
20000:1 18000:1 20000:1 18000:1 20000:1 18000:1
ImageSize(Diagonal) 30–300inches(0.8–7.6m)
ProjectionDistance
(Min.–Max.)
32-507inches(0.8-12.9m) 32–531inches(0.8–13.5m) 32–543inches(0.8–13.8m)
ProjectionAngle 0-16.0(wide)/0-10.0(tele) 0–16.1(wide)/0–9.7(tele) 0–16.1(wide)/0–9.6(tele)
*1 Effectivepixelsaremorethan99.99%.
*2 Thisisthelightoutputvalue(lumens)whenthe[PRESET]modeissetto[HIGH-BRIGHT].Ifanyothermodeisselectedasthe
[PRESET]mode,thelightoutputvaluemaydropslightly.
*3 CompliancewithISO21118-2012
*4 ThemaximumpowerbecomesequivalenttopowerinNORMAL(ECOMODE).
Electrical
Model Number P554U P474U P554W P474W P604X P603X PE523X
Inputs 1×RGB/Component(D-Sub15P),2×HDMITypeA(19P,HDMI
®
Terminal)HDCPsupported*
5
,1×Video(RCA),1×HDBaseT,1×(L/R)
RCAAudio,1×StereoMiniAudio
1×RGB/Component
(D-Sub15P),2×HDMIType
A(19P,HDMI
®
Terminal)
HDCPsupported*
5
,
1×Video(RCA),1×(L/R)
RCAAudio,1×StereoMini
Audio
Outputs 1×RGB(D-Sub15P),1×StereoMiniAudio
PCControl 1×PCControlPort(D-Sub9P)
*5 HDMI
®
(DeepColor,LipSync)withHDCP
 WhatisHDCP/HDCPtechnology?
 HDCPisanacronymforHigh-bandwidthDigitalContentProtection.HighbandwidthDigitalContentProtection(HDCP)isa
systemforpreventingillegalcopyingofvideodatasentoveraHigh-DenitionMultimediaInterface(HDMI).
 IfyouareunabletoviewmaterialviatheHDMIinput,thisdoesnotnecessarilymeantheprojectorisnotfunctioningproperly.
WiththeimplementationofHDCP,theremaybecasesinwhichcertaincontentisprotectedwithHDCPandmightnotbedis-
playedduetothedecision/intentionoftheHDCPcommunity(DigitalContentProtection,LLC).
 Video:DeepColor;8/10/12-bit,LipSync
 Audio:LPCM;upto2ch,samplerate32/44.1/48KHz,samplebit;16/20/24-bit
