1. Introduction
Terminal Panel Features
1. COMPUTER IN/ Component Input Terminal
(MiniD-Sub15Pin)
(→page93,97)
2. COMPUTERAUDIOINMiniJack(StereoMini)
(→page93,94,97)
3. HDMI1INTerminal(TypeA)
(→page93,94,98)
4. HDMI2INTerminal(TypeA)
(→page93,94,98)
5. SERVICEPort(USBTypeB)
 (forservicepurposeonly)
6. COMPUTEROUTTerminal(MiniD-Sub15Pin)
(→page95)
7. AUDIOOUTMiniJack(StereoMini)
(→page95)
NOTE:TheAUDIO OUT mini jack does not support earphone/
headphoneterminal.
8. VIDEOINTerminal(RCA)
(→page96)
9. AUDIOINL,R(RCA)
(→page96)
10.LANPort(RJ-45)
(→page99)
11.USBPort(TypeA)
For USB memory
(→page100)
12.PCCONTROLPort(D-Sub9Pin)
(→page127)
 Use this port to connect a PC or control system.
Thisenablesyoutocontroltheprojectorusingserial
communicationprotocol.Ifyouarewritingyourown
program,typicalPCcontrolcodesareonpage127.
13.HDBaseTPort(RJ-45)
(→page73,103)
1
2
43131011
98712 6
5
