8. Appendix
❹ Attaching the Optional Cable Cover (NP12CV)
Afternishingconnections,attachthesuppliedcablecovertoproperlyhidethecables.
CAUTION:
• Besuretotightenthescrewsafterattachingthecablecover.Failuretodosomaycausethecablecoverto
comeoffandfall,resultingininjuryordamagetothecablecover.
• Donotputbundledcablesinthecablecover.Doingsomaydamagethepowercord,resultinginare.
• Donotholdthecablecoverwhilemovingtheprojectorordonotapplyexcessiveforcetothecablecover.
Doingsomaydamagethecablecover,resultingininjury.
Attaching the cable cover
Tool needed:
• Phillipsscrewdriver(plus-head)about12cm/4.7inchesinlength
12 cm/4.7 inches
1. Align the left and right fixing screw holes on the cable cover
and the projector, and then put screws to each hole.
NOTE:
• Becarefulnottogetcablescaughtinbetweenthecablecoverandthe
projector.
Cable cover fixing screw hole
Fixing screw
2. Tighten the cable cover screws.
• Besuretotightenthescrews.
