8. Appendix
❹ Specifications
Model name PX1005QL-W/PX1005QL-B
Method Single DLP
®
chip
Specications of main parts
DMD panel Size 0.66" (aspect ratio: 16:9)
Pixels
(*1)
4,150,047 (2716 dots × 1528 lines)
Projection lenses
Please refer to the specications of option lens (→ page 153)
Light source Laser Diode
Optical device Optical isolation by dichroic mirror, combining by dichroic prism
Display resolution 8,294,400 (3840 dots × 2160 lines)
Light output
(*2) (*3)
10000 lm
Contrast ratio
(*2)
(all white/all black) 10,000:1 with dynamic contrast
Screen size (throw distance)
Please refer to the “Throw distance and screen size” (→ page 143)
Color reproducibility 10-bit color processing (approx. 1.07 billion colors)
Scanning frequency Horizontal Digital: 15 kHz, 24 to 153 kHz, conforming to VESA standards
Vertical Digital: 24, 25, 30, 48 Hz, 50 to 85 Hz, 100, 120 Hz conforming to VESA standards
Main adjustment functions Power zoom, power focus, power lens shift, input signal switching (HDMI/DisplayPort/
SDI/HDBaseT/SLOT), auto image adjustment, picture maginication, muting (video),
power on/standby, on-screen display/selection, etc.
Max. display resolution (horizontal ×
vertical)
Digital: 4096 × 2160 (handled with Advanced AccuBlend)
Input/output terminals
HDMI Video input HDMI
®
Connector type A × 2
Deep Color (color depth): 8-/10-/12-bit compatible
Colorimetry: RGB, YCbCr444, YCbCr422, YCbCr420, REC2020, REC709, REC601
Supports HDCP
(*4)
, 4K and HDR
DisplayPort Video input DisplayPort × 2
Data rate: 5.4 Gbps/2.7 Gbps/1.62 Gbps
No. lanes: 1 lane/2 lanes/4 lanes
Deep Color (color depth): 8-/10-/12-bit compatible
Colorimetry: RGB, YCbCr444, YCbCr422, REC709, REC601
Supports HDCP
(*4)
, 4K
Ethernet/HDBaseT
port
Video input RJ-45 × 1, 100BASE-TX
Deep Color (color depth): 8-/10-/12-bit compatible
Colorimetry: RGB, YCbCr444, YCbCr422, YCbCr420, BT2020, REC709, REC601
Supports HDCP
(*4)
, 4K
SDI (3G/HD) Video input BNC × 4
Input signals: SMPTE259M, SMPTE292M, SMPTE424M
Colorimetry: RGB, YCbCr444, YCbCr422
PC control terminal D-Sub 9-pin × 1
USB port USB type A × 1
LAN port RJ-45 × 1, Supports 10BASE-T/100BASE-TX
Remote terminal Stereo mini jack × 1
SLOT For mounting separately sold options
Usage environment
(*5)
Operating temperature: 41 to 104°F (5 to 40°C)
Operating humidity: 20 to 80% (with no condensation)
Storage temperature: 14 to 140°F (-10 to 60°C)
Storage humidity: 20 to 80% (with no condensation)
Operating altitude: 0 to 3000 m/10,000 feet
Power supply 110-240 V AC, 50/60Hz
Power con-
sumption
REF.
LIGHT
MODE
NORMAL 1181 W (110-130 V)/1222 W (200-240 V)
ECO1 1002 W (110-130 V)/977 W (200-240 V)
ECO2 658 W (110-130 V)/646 W (200-240 V)
STAND-
BY
Link-up 0.88 W (110-130 V)/0.92 W (200-240 V)
Link-down 0.33 W (110-130 V)/0.35 W (200-240 V)
Rated input current 12.5 A-5.5 A
Power cord specication 15 A or higher
(*6)
External dimensions 19.7" (width) × 8.3" (height) × 22.7" (depth)/500 (width) × 211 (height) × 577 (depth)
mm (not including protruding parts)
19.7" (width) × 8.5" (height) × 23.0" (depth)/500 (width) × 216 (height) × 583 (depth)
mm (including protruding parts)
Weight 68.8 lbs/31.2 kg (not including lens)
