NEC PX803UL User Manual

NEC Display Solutions of America, Inc.
PX803UL/PX1004UL Installation Guide
Desktop and Ceiling Mount Rev 1.2
www.necdisplay.com PX803UL/PX1004UL Page 2 of 12
Formulas: 16:10 Aspect Ratio (WUXGA)
The Projection Formulas use the image width for calculation. Image width is the same for all aspect ratios, only vertical image size
varies. For proper projector placement, determine the image width for a desired screen size. Use the Screen Formulas below to
calculate all screen dimensions. Plug in the image width for “W” in the Projection Formulas.
Refer to the diagrams and charts for popular screen sizes on page 2 and 3:
Projection Formulas: Definitions: 16:10 Screen Formulas
NP16FL: C = 0.794W – 1.85 W = Image Width W = H x 16/10
NP17ZL: C(Wide) = 1.281W – 2.094 ------ C(Tele) = 1.825W – 1.913 H = Image Height (size) H = W x 10/16
NP18ZL: C(Wide) = 1.764W – 2.677 ------ C(Tele) = 2.313W – 2.638 C = Throw distance Screen Diagonal = W x 18.868/16
NP19ZL: C(Wide) = 2.261W – 3.150 ------ C(Tele) = 3.747W – 3.114 16:9 Screen Formulas
NP20ZL: C(Wide) = 3.654W – 5.319 ------ C(Tele) = 5.492W – 5.299 W = H x 16/9
NP21ZL: C(Wide) = 5.469W – 11.626 ---- C(Tele) = 8.527W – 11.531 H = W x 9/16
NP31ZL: C(Wide) = 0.775W – 1.839 ------ C(Tele) = 0.970W – 1.740 Screen Diagonal = W x 18.358/16
NP39ML: Ultra-Short Throw lens (See page 3 for Formulas)
Distance Chart for popular 16:10 Screens (WUXGA)
Distance Chart using 16:9 native projector with 16:9 Image (1080p)
Rear Lens
NP16FL
Diagonal
Width(W)
Height (H) 0.76:1
inches inches inches inches
40 34 21 25.08 24.4 - 31.2 41.4 - 60.0 57.2 - 75.8 73.5 - 124.0 118.6 - 181.0 173.9 - 277.7
60 51 32 38.55 37.6 - 47.6 63.1 - 90.9 87.1 - 115.0 111.9 - 187.5 180.6 - 274.1 266.6 - 422.3
68 58 36 43.94 42.9 - 54.2 71.8 - 103.3 99.0 - 130.7 127.2 - 213.0 205.4 - 311.4 303.7 - 480.2
72 61 38 46.63 45.5 - 57.5 76.1 - 109.5 105.0 - 138.6 134.9 - 225.7 217.8 - 330.0 322.3 - 509.1
85 72 45 55.38 54.0 - 68.2 90.2 - 129.6 124.5 - 164.1 159.8 - 267.0 258.1 - 390.6 382.6 - 603.1
108 92 57 70.87 69.1 - 87.1 115.2 - 165.2 158.9 - 209.2 203.9 - 340.0 329.3 - 497.7 489.2 - 769.4
113 96 60 74.23 72.4 - 91.2 120.7 - 173.0 166.4 - 219.0 213.5 - 355.9 344.8 - 521.0 512.4 - 805.6
130 110 69 85.68 83.6 - 105.2 139.1 - 199.3 191.8 - 252.3 246.1 - 410.0 397.5 - 600.1 591.3 - 928.5
137 116 73 90.39 88.2 - 111.0 146.7 - 210.1 202.3 - 266.1 259.5 - 432.2 419.2 - 632.7 623.7 - 979.1
170 144 90 112.61 109.9 - 138.1 182.6 - 261.2 251.6 - 330.8 322.8 - 537.1 521.4 - 786.4 776.8 - 1217.7
189 160 100 125.41 122.4 - 153.7 203.2 - 290.6 280.0 - 368.1 359.2 - 597.4 580.3 - 874.9 864.9 - 1355.1
208 176 110 138.20 134.9 - 169.4 223.9 - 320.0 308.5 - 405.3 395.7 - 657.8 639.2 - 963.4 953.0 - 1492.5
226 192 120 150.32 146.7 - 184.2 243.4 - 347.8 335.4 - 440.6 430.2 - 715.0 695.0 - 1047.2 1036.5 - 1622.6
270 229 143 179.94 175.6 - 220.4 291.2 - 415.9 401.2 - 526.9 514.5 - 854.8 831.3 - 1252.1 1240.6 - 1940.8
300 254 159 NA 195.3 - 245.0 376.6 - 753.6 748.4 - 1200.2 1183.2 - 1829.4 1379.7 - 2157.7 1379.7 - 2157.7
inches
inches
inches
1.73-2.27-1
Screen Size (16:10)
2.22-3.67:1
NP31ZL
NP17ZL
NP18ZL
NP19ZL
Zoom Lenses
NP21ZL
5.30-8.30:1
0.75-0.93:1
1.29-1.79:1
inches
inches
inches
NP20ZL
3.60-5.40:1
Rear Lens
NP16FL
Diagonal
Width(W)
Height (H) 0.76:1
inches inches inches inches
39 34 19 25.15 24.5 - 31.2 41.5 - 60.1 57.3 - 76.0 73.7 - 124.3 118.9 - 181.4 174.3 - 278.4
59 51 29 38.64 37.7 - 47.7 63.2 - 91.2 87.3 - 115.3 112.2 - 188.0 181.0 - 274.8 267.3 - 423.3
67 58 33 44.20 43.1 - 54.5 72.2 - 103.9 99.6 - 131.5 128.0 - 214.2 206.6 - 313.2 305.6 - 483.0
70 61 34 46.58 45.4 - 57.4 76.0 - 109.4 104.9 - 138.5 134.8 - 225.5 217.6 - 329.7 322.0 - 508.6
83 72 41 55.32 54.0 - 68.1 90.1 - 129.5 124.3 - 163.9 159.6 - 266.7 257.8 - 390.1 382.1 - 602.4
106 92 52 71.20 69.5 - 87.5 115.8 - 166.0 159.6 - 210.2 204.9 - 341.6 330.8 - 500.0 491.5 - 773.0
110 96 54 74.37 72.6 - 91.4 120.9 - 173.3 166.7 - 219.4 213.9 - 356.6 345.5 - 521.9 513.4 - 807.1
126 110 62 85.49 83.4 - 105.0 138.8 - 198.8 191.4 - 251.8 245.6 - 409.1 396.6 - 598.8 590.0 - 926.4
133 116 65 90.25 88.1 - 110.8 146.5 - 209.8 201.9 - 265.7 259.1 - 431.5 418.5 - 631.8 622.8 - 977.6
159 139 78 108.52 105.9 - 133.1 176.0 - 251.8 242.5 - 318.9 311.1 - 517.7 502.6 - 758.1 748.6 - 1173.7
184 160 90 125.19 122.2 - 153.5 202.9 - 290.1 279.6 - 367.4 358.6 - 596.4 579.3 - 873.4 863.4 - 1352.8
202 176 99 137.89 134.6 - 169.0 223.4 - 319.3 307.8 - 404.5 394.8 - 656.4 637.8 - 961.3 950.9 - 1489.2
220 192 108 150.60 147.0 - 184.5 243.9 - 348.5 336.0 - 441.5 431.0 - 716.3 696.2 - 1049.2 1038.4 - 1625.7
263 229 129 179.98 175.6 - 220.4 291.3 - 416.0 401.3 - 527.0 514.6 - 854.9 831.4 - 1252.4 1240.8 - 1941.2
299 261 147 NA 200.4 - 251.4 386.4 - 773.2 768.0 - 1231.5 1214.1 - 1877.1 1252.4 - 2214.0 1415.8 - 2214.0
inches
Screen Size (16:9)
2.22-3.67:1
NP31ZL
NP17ZL
NP18ZL
NP19ZL
1.73-2.27-1
Zoom Lenses
NP21ZL
0.75-0.93:1
1.29-1.79:1
inches
inches
5.30-8.30:1
NP20ZL
3.60-5.40:1
inches
inches
inches

NEC PX803UL Specifications

General

Matrix size	0.67 \
Native aspect ratio	16:10
Projection distance	0.86 - 118 m
Vertical scan range	48 - 120 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	DLP
Supported aspect ratios	4:3, 5:4, 15:9, 16:10, 16:9, 17:9
Contrast ratio (typical)	10000:1
Screen size compatibility	40 - 500 \
Projector native resolution	WUXGA (1920x1200)
Keystone correction, horizontal	-40 - 40 °
Light source type	Laser
Service life of light source	20000 h
Power source	AC
Power consumption (standby)	- W
Power consumption (typical)	850 W
3D	Yes
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	640 x 480 (VGA), 1920 x 1200 (WUXGA), 2048 x 1080, 2560 x 1600 (WQXGA), 4096 x 2160
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black
DVI port	No
Audio (L/R) in	0
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	-
Noise level	40 dB
Certification	CE, ErP, TÜV GS
Noise level (economic mode)	35 dB
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	RoHS
Remote control type	IR
Focus	Auto
Focal length range	- mm
Optical disc player type	Not included
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	577 mm
Width	500 mm
Height	211 mm
Weight	28000 g
