Topaz Configuration Mode
Topaz Configuration Mode
Entering Configuration Mode
• You will need a Topaz system phone with an LCD display.
• The phone should be idle (no call in progress).
1 Press SPK
(do not lift the handset)
You will see -
2 Dial Service Code # * # * You will see -
3 Dial password 12345678 You will see -
4 Press HOLD You will see -
MON 27 16:28PM
200 EXT200
Password
Password@@@@@@@@
_
Pro
g
ram Mode
Selecting the Program Number
• Each configuration setting within the Topaz is identified by a Program Number (eg 22-05-01).
_
Pro
g
ram Mode
1
Ensure the LCD display
shows:
2
If it is not displayed press the
DC key several times.
3
Now enter the Program
Number e.g. 22 05 01 with the
numeric keys of the Topaz
phone.
22-05-01 Trunk1
Mode1 IRG =1
Using the System Phone Keys to Make Changes
• During configuration mode use the keys at the system phone to select the program item and change its
value etc.
• The LCD display will show the current program item, the editing point is shown by a flashing curser.
SPK
Save changes and exit configuration mode.
Numeric keys
1 to 9 * and #
Alphanumeric entry keys. Entered at the curser location.
HOLD
Confirm the entry and step on to the next.
DC
Step back one level. Current entry is not confirmed.
DND/CONF
Delete one character to the left of the curser.
CLEAR
Delete all characters to the right of the curser.
LND
Move the curser one character to the left.
OPAC
Move the curser one character to the right.
Vol. up
Confirm the entry and step to the next item shown at the top right of the display.
Vol. down
Confirm the entry and step to the previous item shown at the top right of the display.
FLASH
Move the curser to the next entry point.
22 Topaz 2PGDU Guide
