NEC Versa Note VX Series - Page 46

Disassembly and Reassembly 3-11
3. Remove the ten screws on the bottom that secure the top cover to the system.
Removing the bottom screws
A – Screws
4. Turn the system over.
5. Locate and remove the one screw inside the hard disk drive bay that secures the top cover.
Removing the drive bay screw
A – Screw
