System Overview 1-5
C – Caps Lock Lock
n Hard Drive Access — lights when the Versa Note VX accesses the hard disk drive,
CD-ROM drive or DVD-ROM drive.
n Diskette Drive Access — lights when the Versa Note VX writes data to or retrieves data
from the diskette drive.
n Caps Lock — lights when caps lock is in effect.
n Scroll Lock — lights when scroll lock is in effect.
n Num Lock — lights when Num Lock mode is active.
Keyboard Panel and Base Unit
The Versa Note VX keyboard panel and base unit contain the following features. The keyboard
panel and base unit features are described after the figure.
Keyboard panel
A – Keyboard B – VersaGlide
Base unit
A – Speakers D – Audio Ports
B – IR Port E – Volume Control
C – Microphone
