NEC Versa Note VX Series - Connector Locations

6 Specifications
Connector Locations
The following table shows the system’s connector locations.
Connector Locations
Connector Location
P1 Audio Board
P2 Audio Board
P1 I/O Board
P5 I/O Board
P6 I/O Board
P8 I/O Board
P2 Main Board
P5 Main Board
P7 Main Board
P9 Main Board
P10 Main Board
P12 Main Board
