NEC VT700 - Using Two Analog COMPUTER Inputs Simultaneously

13
AUDIO OUT
AUDIO IN
MONITOR OUT (COMP 1)
COMPUTER 1 IN COMPUTER 2 (DVI-I) IN
AUDIO IN
S-VIDEO
IN
VIDEO IN
PC CTRL
L
R
COMPUTER 1 IN
COMPUTER 2 (DVI-I) IN
VGA signal cable
(supplied)
IBM PC or Compatibles (Notebook type)
or Macintosh (Notebook type)
IBM PC or Compatibles (Desktop
type) or Macintosh (Desktop type)
VGA signal cable (not
supplied)
DVI to VGA adapter
(supplied)
2. Installation and Connections
NOTE: When the DVI to VGA adapter is not to be used for an extended period of time, remove it from the projector. Failure to do
so may cause damage to the connector of the projector.
Using Two Analog COMPUTER Inputs Simultaneously
If you need to use two analog COMPUTER inputs simultaneously, connect a VGA signal cable as shown below.
