AUTOTEST
This function allows testing of the main machine compo-
nents.
Before carrying out this operation, remove the waste tray
and the powder containers and disassemble the coffee
unit.
Press button “4” and the message “AUTOTEST” will be
start blinking.
Press button “2” to cancel the operation, confirm with
button “6” to start the autotest cycle.
In a sequence:
- the doser devices are activated for 2 seconds
- the mixers are activated for 2 seconds
- a cup is released
- a stirrer is released
- the coffee unit is rotated, coffee is ground and then
released when a full dose is reached.
- the waste tray is detected; the machine stops until the
waste tray is manually re-inserted
- the push-button panel is checked; the machine dis-
plays the number of the button which must be pressed
and waits for this to be done before going to the next
button (number 9 corresponds to the cleaning button).
EMPTYING THE AIR-BREAK
This function is used to partially empty the air-break,
dispensing water from the milk solenoid valve for 8 sec-
onds before blocking the machine, to allow the machine to
be moved without spilling water; to restore normal function-
ing the machine must be switched off and then on.
Before moving the machine on a long distance, especially
if involving the use of a vehicle, the hydraulic system must
be emptied manually.
DISPLAYING THE STATISTICS
Press button " " when the display indicates the “Display
statistics” function; then the stored data will be sequentially
shown on the screen, and more precisely:
With setting to VALIDATOR or TOTALIZER
1 - counter by single selection;
2 - counter by single price;
3 - failure counter;
4 - counter by type of coin cashed;
5 - total cashed counter;
With setting to MDB
1 - counter by single selection;
2 - counter by single price;
3 - failure counter;
4 - MDB Audit; displaying in the actual currency of:
Aud. 1 Money in the tubes
Money present in the change tube that moment
Aud. 2 Money to the tubes
Money sent to the change tubes
Aud. 3 Money to the box
Money sent to the coin box
Aud. 4 Change return
Total money returned
Aud. 5 Excess
Excess money. Extra amounts paid by the customer that
were not returned (in the event there was no money
available for return)
Aud. 6 Release tubes
Value of coins dispensed with the function “Tubes control”
Aud. 7 Loading tubes
Value of money cashed with the manual loading function
Aud. 8 Cash sales
Value of total sales with cash money (coins + bills)
Aud. 9 Cashed bills
Value of cashed bills
Aud. 10 Charge key
Value of money changed into the key
Aud. 11 Sales with key
Value of money cashed for dispensing with key.
PRINT STATISTICS
Connect an RS-232 serial printer with a Baud rate of 9600,
8 data bit, no parity, 1 stop bit to the serial port located on
the push button board, to print all the statistics described
in section “Displaying the statistics”. The hardcopy printout
will also contain the machine code number and the printout
progressive number.
The progressive hard-copy printout number can only be
reset by initialising the machine.
To connect the printer, do as follows:
- Press button “ ” when the display indicates the “Print
statistics” function and the message “Confirm?” will be
displayed;
- before confirming connect and switch on the printer;
- press the confirm button “ ” to start printing.
