19
© by NECTA VENDING SOLUTIONS SpA 03-2003 217 00
PROGRAMMING THE
WATER AND POWDER DOSES
When either the “Wat. dose sett.” or the “Powd. dose sett.”
functions from the “programming” menu are displayed the
related doses can be varied.
The various doses are identified by dose codes, which are
displayed each time.
The dose code locates the water and powder doses related
to a given selection; any changes to one selection dose
also affects the compound selections where the dose code
is used.
Refer to the selection dose table for the dose code list.
The values of the doses displayed are expressed in:
- tenths of a second for powders;
- number of pulses of the volumetric counter for water.
Press the confirm button “ ” from the “programming” menu
to access the dose code list, which can be scrolled with the
“ ” and “ ” buttons.
When pressing correction button “ ”, this value will start
blinking and can be modified as necessary.
PRICE SETTING
When the “Price sett.” (price programming) function from
the “programming” menu is displayed, the 8 sales prices
stored can be changed.
The prices are indicated as number of basic coins.
Press the confirm button “ ” from the “programming” menu
to access the price list, which can be scrolled with the “ ”
and “ ” buttons. When pressing correction button “ ”, this
value will start blinking and can be modified as necessary.
PROGRAMMING THE PRICES
AND THE BUTTON STATUS
When the “Set Price/Button” (price setting) function of the
“programming” menu is displayed, the combination of the
button to one of the stored prices and/or to the status of a
selection can be changed.
Press the confirm button “ ” from the “programming” menu
to access the price list, which can be scrolled with the “ ”
and “ ” buttons. When pressing the correction button “ ”,
the selection status starts blinking. Using the “ ” and “ ”
buttons, the selection status can be changed from (ena-
bled) to (disabled).
Press again the confirm button “ ” to display the price
number referred to in the price table.
When pressing correction button “ ”, this value will start
blinking and can be modified as necessary.
The buttons which control pre-selections do not need
combination with prices. In any case prices have no effect
on the pre-selection buttons.
PROGRAMMING THE BASIC COIN AND
THE DECIMAL POINT
When the “Basic coin / DP” (basic coin value) function from
the “programming” menu is displayed, the value of the
basic coin as well as the position of the decimal point can
be modified.
Press the confirm button “ ” from the “programming” menu
to display the current value of the basic coin.
Using the “ ” and “ ” buttons, the value of the basic coin
and the number of the decimal point position “dP” are
displayed alternately, i.e:
0 decimal point disabled
1 XXX.X
2 XX.XX
3 X.XXX
Press the correction button “ ”, these values will start
blinking and can then be modified as necessary.
PAYMENT SYSTEMS
When the “Payment system” function is displayed, it is
possible to define which payment system with MDB com-
munication protocol to use, selecting among:
- Validator
- MDB
In order to install payment systems different from a validator
or cashless system, special kits must be used.
The payment systems must be housed in the cabinet.
PROGRAMMING THE VALIDATOR
If the payment system is a validator, it will be
necessary to define with which parameters to operate.
CREDIT CONTROL
It is possible to decide whether any excess credit paid is to
be cashed or made available to the user.
OPERATING VOLTAGE
According to the type of validator it is necessary to define
whether the
operating voltage is 12 V or 24 V.
VALIDATOR LINES
When the “Validat. Lines” (line setting) function is dis-
played, the value of the 6 validator coin lines can be
changed.
The value of the lines is indicated as number of basic coins.
Press the confirm button “ ” from the “programming” menu
to access the line list, which can be scrolled with the “ ” and
“ ” buttons.
When pressing correction button “ ”, this value will start
blinking and can be modified as necessary.
