© by NECTA VENDING SOLUTIONS SpA 02-2004 184 02
INITIALS DESCRIPTION
WIRING DIAGRAM LEGEND
INITIALS DESCRIPTION
CM1 COFFEE UNIT MOTOR CAM
CMSB CUP RELEASE MOTOR CAM
CV VOLUMETRIC COUNTER
E1-... INSTANT SOLENOID VALVE
EEA WATER INLET SOLENOID VALVE
ER COFFEE DISPENSER SOLENOID VALV
ERS SLIDER DELAY MAGNET
ESC COFFEE RELEASE MAGNET
EX EXECUTIVE COIN MECH CONNECTOR
FA RADIO INTERFERENCE SUPPRESSOR
FREE FREE VENDING SWITCH
ID COFFEE DOSE SWITCH
IMSP STIRRER RELEASE MICRO-SWITCH
IP DOOR SWITCH
IPF WASTE CONTAINER OVERFLOW SWIT
IVA EMPTY BOILER MICRO-SWITCH
IVB EMPTY CUP DISPENSER MICRO SWITC
JUG JUG FACILITIES SWITCH
KC1-.. COFFEE BOILER CUTOUT
KS1-.. SAFETY CUTOUT
LCD LIQUID CRYSTAL DISPLAY
LF LAMP
M COFFEE UNIT MOTOR
MAC GRINDER
MD1-.. INGREDIENT MOTOR - INSTANT
MDB CONNECTOR FOR MDB COIN MECHANI
MDZ INGREDIENT MOTOR - SUGAR
MF1-.. WHIPPER MOTORS
MPU SPOUT POSITIONING MICROSWITCH
MSB CUP RELEASE MOTOR
MSCB CUP CONTAINER SHIFT MOTOR
MSP STIRRER RELEASE MOTOR
MSU SPOUT MOVING MOTOR
NTC TEMPERATURE PROBE
NTCS INSTANT BOILER TEMPERATURE PRO
PB POWER SUPPLY SOCKET
PIP PROGRAMMING BUTTON
PL WASH CYCLE BUTTON
PM PUMP
PSB CUP RELEASE BUTTON
RCC COFFEE BOILER HEATING ELEMENT
RCS INSTANT BOILER HEATING ELEMENT
RIS COFFEE UNIT HEATER
RS232 SERIAL PORT
SM CONTROL BOARD
SM1 CONTROL BOARD
SM2 EXPANSION BOARD
SP PUSH-BUTTON BOARD
STRC BOILER HEATING TRIAC BOARD
SUC C.P.U. BOARD
TR TRANSFORMER
TX.... DELAYED FUSE (X=COURRENT)
TZ CUP SENSOR
UPS COLD UNIT PRINTED BOARD
VENT FAN
60
