Nelson NCD+ 3200 User Manual

NCD+ 3200 Manual | Connection and Installation
Part No. 729-110-037 Rev. 1.31 | May 2016 © 2014 Nelson Stud Welding, Inc. All Rights Reserved.
1.3 Specifications
NCD+ 3200™ CD WELDING UNIT
MIN.
MAX.
Input Voltage (V) / Current (A)
120/20
Input Line Frequency (Hz)
60
Capacitor Voltage (VDC) (Continuously Adjustable)
70
200
Stored Energy (Ws)
3750
Capacitance (mF) (High/Low Switchable)
81
189
Weight
64 lbs (30 kg)
Weld Rate
(studs/min)
Low Capacitance, 120V
20
High Capacitance, 180V
8
Maximum Stud Thread
Diameter
Steel/Stainless (TFTC/S)
3/8″ Flanged
Aluminum (TFTA)
5/16″ Flanged
Dimensions (Length x Width x Height)
20″ x 13.25″ x 8.5″
(508 mm x 336.5 mm x 216 mm)
Power Cord
9 ft (2.75 m)
Idle Power (W)
80 or less
Operating Temperature (°C)
-20 to +40
Storage Temperature (°C)
-40 to +60
Gun Connector
12-Pin Binder
Weld Connector
Dinse
Dual Ground
Yes
Compatible Guns
NCD+ Contact, NCD+ Auto-Gap
Process Monitor
Yes – Optional
Contact Safety Check
Yes
Chuck Saver
Yes
Stud Expert
Yes
Display
Graphic Color Display
