NCD+ 3200 Manual | Connection and Installation
Part No. 729-110-037 Rev. 1.31 | May 2016 © 2014 Nelson Stud Welding, Inc. All Rights Reserved.
1.2 Connection
With the exception of the input power cable, all of the connections are located on the front plate
of the NCD+.
Prior to any connection work, the NCD+ welding unit must be switched
off. The input power switch must be in the >>0<< position.
1 Gun Welding Cable Connection (-) x1
3 Workpiece Ground Cable Dual Connection (+) x3
2 Gun Control Cable Connection x2
4 Input Power Cable Connection
1
2
4
3
Figure 1.1 NCD+ Connection
2
1
