Nelson NCD+ 3200 User Manual

NCD+ 3200 Manual | NCD+ 3200 Parts List & Exploded View
Part No. 729-110-037 Rev. 1.31 | May 2016 © 2014 Nelson Stud Welding, Inc. All Rights Reserved.
32
5
524-005-339
Nut, Hex, M6, SS
20 in/lbs
33
10
524-005-273
Nut, KEPS, M6, SS
20 in/lbs
34
1
524-005-279
Screw, M4 x 16, PHMS, SS
10 in/lbs
35
1
750-614-229
NCD+ 3200 Shunt Connector
36
16
524-005-311
Washer, Belleville, M6, SS
14
37
33
524-001-309
Washer, Flat, 1/4″, SS
14
38
1
717-999-013
Fan
39
1
714-033-000
Grommet
40
3
524-005-270
Screw, M4 x 60 PHMS, SS
20 in/lbs
41
4
524-005-272
Nut, KEPS, M3, SS
10 in/lbs
42
1
723-247-108
Transformer Assembly
43
2
724-462-010
Nelson Logo Decal
44
3
524-005-337
All Thread, M6 x 160
45
2
524-005-293
Screw, M6 x 30, HHCS, SS
80 in/lbs
46
0.4″
103-479-000
Thermal Tape
47
1
750-614-060
NCD+ Power Board Assembly
1
48
17
524-005-326
Screw, M6 x 14, HHCS, SS
40 in/lbs
14
49
1
724-576-017
NCD+ 3200 Rating Decal
50
1
724-485-010
Electrical Ground Label
51
1
524-005-289
Nut, M8 SS
52
1
87-05-19
Unplug Before Service Label
53
1
724-569-000
Warning Label
54
1
724-576-015
Made In USA Label
55
4
524-005-329
Screw, M8 x 12 PHMS, SS
40 in/lbs
56
5
524-005-288
Lock Washer, M8, SS
57
7
702-119-000
Capacitor, 27mf
2
58
5
524-005-287
Washer, M8 Flat, SS
60 in/lbs
59
4
524-005-271
Screw, M3 x 12 PHMS, SS
10 in/lbs
60
1
87-09-35
Cardiac Pacemaker Label
61
6
724-485-015
Small High Voltage Label
62
2
524-005-302
Washer, M3 Flat, SS
63
1
524-005-354
Screw, M8 X 16 HHCS, SS
NS
1
723-247-101
Power Board to Control Board Harness
NS
1
723-247-102
Power Board to Shunt, XFMR,
Discharge Resistor & Cap Switch Harness
