Nelson Nelweld 6000 - Page 43

Nelweld Operations and Service Manual
- 43 -
Maximum Cable Length: Nelweld 4000
600 750 900
1050 1200 1350 1500 1650 1800 1950 2100
10 33 66 98 131 164 197 230 262 295 328 361 394 427 459 492 525 558 591 623 656
3 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200
Cable Length (ft or m), including ground cable
Current (amps)
feet meters
4/0 (0000), 120mm
2
95mm
2
3/0 (000), 85mm
2
2/0 (00), 70mm
2
1/0 (0), 50mm
2
Example: Desired current = 1500 A Maximum Weld Cable Length: 1/0, 50mm
2
: 228 ft (68 m)
2/0, 70mm
2
: 327 ft (96m)
3/0, 85mm
2
: 393 ft (119m)
95mm
2
: 440 ft (134m)
4/0, 120mm
2
: 558 ft (170m)
Note: Some
4/O cable is 107sqmm, which falls
between the
95sqmm and
120sqmm
