NW511
11
Keytosingle‐phase/three‐phaseelectricalsystemdiagram
NTCB BoilertemperatureprobeEVA Aquastopsolenoidvalve
NTCV TanktemperatureprobeEVR Regenerationsolenoidvalve
SDET DetergentsensorEVS Brinedischargesolenoidvalve
SBRIL RinseaidsensorPB Rinseaidperistalticpump
SFIL FiltersensorPD Detergentperistalticpump
FLMT FlowmeterEVF Fillersolenoidvalve
SS SaltsensorPS Drain
pump
RD DoorsensorPLB Boilerpressureswitch
PR RinsingpumpPLV Tanklevelpressureswitch
PL WashingpumpPSV Tanksafetypressureswitch
PLB BoilerlevelpressureswitchAQS Aquastopmicroswitch
THB BoilersafetythermostatSB Motherboard
M TerminalboardSI Interfaceboard
LF RFIfilter TM Terminalboard
ground
FUSE MainsfuseTV Tankground
CB BoilercontactorTF RFIfilterground
RB BoilerheatingelementTPL Washingpumpground
T‐FU OvertemperaturefuseTPR Rinsingpumpground
THRV TanksafetythermostatTRV Tankheatingelementground
RV TankheatingelementTB Boilerheatingelementground
Figure–Appliancethree‐phaseelectricalsystemdiagram
