NW511
17
5.6 Adjustingdetergentandrinseaiddispensing
Caution:ensurethattheapplianceisnotpoweredup‐ELECTRICSHOCKHAZARD
RV
RV
RD
RD:Detergentdispensingregulatorscrew.
(onsomemodelsonly)
Adjustments are made using the adjuster
screwASSHOWN.Thequantitydispensedis
reduced by turning anticlockwise and
increasedbyturningclockwise.
RB:Rinseaiddispensingregulatorscrew
AdjustmentsaremadeusingtheadjusterscrewAS
SHOWN. The quantity dispensed is reduced by
turning clockwise and increased by turning
anticlockwise.

Itisrecommendedthatperiodicmonitoringofdetergentandrinseaiddispensing;every15.000cycles
suggestedreplacetheinnerperistalticpipe
RD Detergentdispensingregulatorscrew(onsomemodelsonly)
RB Rinseaiddispensingregulatorscrew
RV Inspectionpanelremovalscrew
