NW511



9

POSITIONING:



4 INSTRUCTIONS FOR TECHNICAL STAFF

4.1 Plumbingconnection



Watersupplyanddrainconnection

Thewaterpipelinesandelectricitysupplycableleadoutofthebottomright‐

handcorneroftheappliance.Connectthewaterintakehosetoaconnector

with ¾” gas threaded fitting, fitting the filter A provided (in models with

aquastop,thefilterandring‐nutformasingleunit).

Theconnectiontothewatermainsmustonlybemadewithnewhoses;the

useofoldorwornhosesisnotpermitted.

Thedynamicwatersupplypressure mustbebetween1and6bar;ifitishigherapressurereducer

mustbeinstalled.

Itisessentialtofitamainstoptaponthewaterintakedeliverpipeline;thetapmustbeaccessible

afterinstallationoftheappliance,sodonot

installitbehindthewarewasher.Thestatedcycle

durationappliestoappliancessuppliedwithhotwater>50°C<60°CIfthewarewasherissupplied

withcoldwater,thecycledurationmightincreasedependingontheintakewatertemperature.





Caution:theindoorsystemandpremisesinwhichequipmentforinstitutionsisinstalled

mustcomplywiththerelevantregulations.

Themanufacturerdeclinesallliabilityfordirectorindirectinjuryordamagederivingfromfailure 

tocomplywiththeseregulations.

Before installation, check that there are no objects or  materials in the vicinity which may be

damagedbysteamorsplashesofwashingsolution,orthatanysuchitemsaresuitablyprotected.

Placethewarewasherinthechosenpointandremovetheprotectivefilm.

Level the warewasher (with the aid of a spirit level) on its adjustable feet to ensure that it is

stable;allothermountingsolutionsmustbeapprovedbythemanufacturer.


