8.1 Dailycleaningoffilters

Cleaningthefilterattheendofeachworkingday

Remove the filters (simply lift them out as shown here), taking care
that no large residues fall into the sump underneath. Clean them to
remove residues and rinse with plenty of water, then put them
correctlybackinplace;donotusesharporpointedtools.
Cleanawayanylimescaledepositstopreventexcessivebuild‐ups;

8.2 Routineinspectionofthesprayarms(twiceaweek)
Removethetopandbottomsprayarmsbyunscrewingthecentralscrewandunscrewthecapsfromthe 
endsoftherinsingarmsasshown.Donotunscrewthenozzles.Cleantheholesandnozzlesunderajet
ofcleanrunning water;do notuse  toolswhichmight causedamage.Reassemble thesprayarmswith
care.

TOPSPRAYARMS BOTTOMSPRAYARMS
3
1
2



Cleantheoutsideoftheappliancewithadampclothandneutralsoap,rinsinganddryingthoroughly.
8.3 Lengthyperiodsoutofuse
If the warewasher is to be out of use for a fairly long period of time, the detergent and rinse aid
dispenserdevicesmustbe emptiedtopreventcrystallisationand damagetothepumps: removethe
intakehosesfromthedetergentandrinseaidcontainersandplacetheminacontainerofcleanwater,
thenperformafewwashcyclesfollowedbyacompletepump‐out.

Finally,turnoffthemasterswitch,closethewaterintakevalveandleavethedoorajaruntiltheinterior
iscompletelydry.Thedetergentandrinseaidintakehosesmustbeputbackintothecontainerswhen
thewarewasherisreturnedtoservice,takingcarenottoswapthemover(redhose= detergent,blue
hose=rinseaid).
