5 Software Setup B
13
5.2.5 History Channel 2
• The alarm and error history for all configured sensors on channel 1 are
given. Refer to 3.2.4 for further detail.
5.2.6 Event Log
• All system events and the time of the event can be viewed.
• Use the centre pushbutton to enter and exit the log and the left and right
pushbutton to cycle through the log.
• Log entries cannot be deleted.
• If an event recurs within a configurable amount of time, the event will only
be logged once in that time. Refer to section 3.3.3 to change the time
threshold.
5.2.7 System restart
• The software revision is displayed here.
• Hold the centre pushbutton for 2 seconds to initiate a system restart.
Any unsaved configuration changes will be lost.
5.3 Installer Menus
The installer menus can be accessed by holding down any of the pushbutton during system
power up or restart. Like the user menus, scrolling through the different menus is done
with the left and right pushbuttons.
To automatically address a new installation, execute the following steps in order, by
referring to the relevant menus below:
• Decommission channel 1/2 (section 5.3.1.1)
• Count sensors on channel 1/2 (section 5.3.1.2)
• Address sensors on channel 1/2 (section 5.3.1.3
• Exit the channel installer menu (section 5.3.1.6)
• Save the configuration (5.3.4)
5.3.1 Channel 1 installer menu
Channel 1 can be configured by pressing the centre pushbutton to access the
following submenus:
5.3.1.1 Decommission Channel 1
• Pressing the centre pushbutton for 2 seconds will clear all Taut Wire sensor
addresses to 0 and return the sensor alarm threshold to factory default.
• This action should be performed on all new installations, BEFORE continuing
with sensor addressing.
