4.4 Node Board Layout
8
Board
Power
Supply
Channel 1
Relay
Output
Channel 2
Relay
Output
12V
Output
Digital
Outputs
Ground
Digital
Inputs
OLED Display
Relay Configuration
Jumpers
Taut Wire Sensor
Channel 1
Taut Wire Sensor
Channel 2
RJ45
Network
Connection
Configuration
Push Buttons
