Page 12
Installing the GPS Antenna
The diameter of the mounting pole supported is 1
5/8” to 2 3/8” (40-60 mm).
Required Items
• 1x adjustable wrench
• 1x GPS w/ Accessories
Installation Procedure
1. Open the packaging, take out the antenna,
mounting kit, and the mounting pipe.
2. Insert the cable connector into the mounting
pipe, connect the cable with the antenna
connector and screw it down. Torque the
connector to 15 in-lbs.
3. Connect the mounting pipe and the antenna
and screw it down.
4. Attach the antenna to the clamp with the
fastening accessories and lock it down.
5. Fix the clamp to the mounting pole with the u
bolt and the fastening accessories.
6. Check that all bolts and nuts are tightened
completely.
7. Secure the cable to the mounting pole with
the cable strip.
8. Connect the coax to the GPS port on the
gateway. Care should be taken not to
damage the RF connectors while tightening.
Care should be taken not to exceed the bend
radius of the coax.
9. Weatherproof the RF connection using
Scotch P/N: WK-101.
