PoE
Enable PoE: Slide the toggle switch right to enable
the PoE test portion of AutoTest, and slide left to
disable it.
Class: Touch the down caret to the right of the
field to select a PoE class setting to match your
switch's (or PoE injector's) available class. The
LinkRunner G2 supports Cisco's UPOE, which can
provide up to 51 W, as well as 802.3bt classes 5-8.
Select the Injector option if you are using a non-
IEEE injector.
NOTE: LR G2 may not receive the total wattage
advertised by your switch or injector because of
power loss over the cable.
LLDP: This field appears if Class 4 (25.50 W) is
selected. Class 4 LLDPmust be enabled on the
switch for AutoTest to detect it successfully.
NOTE: If a switch does not support LLDP and the
LLDP setting is enabled on LR G2, LLDP nego-
tiation will fail, but it will not affect the rest of the
AutoTest.
Request Power (W): This field appears if the
UPOE class is selected. Touch the field to open a
38
LinkRunner G2 Application Settings
