Do not completely insert the controller module in the chassis until instructed to do so.
3. Recable the system, as needed.
If you removed the transceivers (QSFPs or SFPs), remember to reinstall them if you are using fiber optic
cables.
4. Complete the reinstallation of the controller module:
a. Firmly push the controller module into the chassis until it meets the midplane and is fully seated.
The locking latches rise when the controller module is fully seated.
Do not use excessive force when sliding the controller module into the chassis to avoid
damaging the connectors.
a. Rotate the locking latches upward into the locked position.
5. Plug the power cords into the power supplies.
If you have DC power supplies, reconnect the power block to the power supplies after the
controller module is fully seated in the chassis.
The controller module boots when power is restored. If it boots to the LOADER prompt, reboot the
controller with the
boot_ontap command.
6.
Restore automatic giveback if you disabled it by using the
storage failover modify -node local
-auto-giveback true
command.
7.
If AutoSupport is enabled, restore/unsuppress automatic case creation by using the
system node
autosupport invoke -node * -type all -message MAINT=END
command.
Step 5: Return the failed part to NetApp
Return the failed part to NetApp, as described in the RMA instructions shipped with the kit. See the
Part Return
& Replacements
page for further information.
I/O module
Overview of add and replace I/O module - AFF A70-90K
You can replace a failed I/O module in your storage system with the same type of I/O
module, or with a different kind of I/O module. You can also add an I/O module into a
system with empty slots.
Add I/O module - AFF A70, AFF A90
You can add an I/O module to your storage system by either adding a new I/O module
into a storage system with empty slots or by replacing an I/O module with a new one in a
fully-populated storage system.
72
