NetApp DS4246 User Manual

SAS disk shelf safety information
Before you install the shelf, you need to be aware of safety information about the physical
installation, power and electrical, and management of your disk shelf.
DANGER: Failure to follow these directions could
result in bodily harm or death.
CAUTION: If this equipment is used in a manner not
specified by the manufacturer, the protection provided by
the equipment might be impaired.
Physical installation safety rules
Power and electrical safety rules
Management safety rules
Before installing the disk shelf, make sure that you have read and understand these physical
installation safety rules.
• The rack construction must be capable of supporting the total weight of the installed enclosures
and the design should incorporate stabilizing features to prevent the rack from tipping or being
pushed over during installation or in normal use.
• When installing disk shelves and a storage system into a movable cabinet or rack, install from
the bottom up for best stability.
• A fully loaded disk shelf is heavy. Do not try to lift it by yourself.
Before moving the enclosure, you can remove all Power Supply Units (PSUs) and I/O Modules
(IOMs) to minimize weight.
◦ A fully loaded DS4243 or DS4246 disk shelf can weigh approximately 110 lbs. (50 kg).
◦ A fully loaded DS2246 disk shelf can weigh approximately 49 lbs (22 kg).
◦ A fully loaded DS4486 disk shelf can weigh approximately150 lbs (68 kg). With only the
two IOMs, four PSUs, and four disk carriers installed, the disk shelf can weigh
approximately 82 lbs (37 kg).
• A safe lifting height is 20U.
• Do not lift the enclosure by the handles on the PSUs.
They are not designed to take the weight.
• Ensure that the socket outlets are located near the equipment and are easily accessible since the
plug on the power supply cord is used as the main disconnect device.
• The rack, when configured with the units, must meet the safety requirements of UL 60950-1
and IEC 60950-1.
DS4243, DS2246, DS4486, and DS4246 Installation and Service Guide 4
SAS disk shelf safety information

NetApp DS4246 Specifications

General

Data transfer rate	6 Gbit/s
Storage drive size	3.5 \
Storage drive interface	Serial Attached SCSI (SAS)
Storage drives installed	Yes
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	40.8 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	24
Chassis type	Rack (4U)
Product color	Black
Device class	Large Enterprise Business
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Number of power supply units	2
Operating altitude	0 - 3045 m
Non-operating altitude	-305 - 12192 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	610 mm
Width	483 mm
Height	178 mm
